                            State of California
                            AIR RESOURCES BOARD

                            EXECUTIVE ORDER D—54—4
                Relating to Exemptions under Section 27156
                         °_ of the Vehicle Code

                      PRESTOLITE ELECTRICAL DIVISION
                        IHC "FLEETRITE" BREAKERLESS
                         INDUCTIVE IGNITION SYSTEM


 Pursuant to the authority vested in the Air Resources Board by Section
 27156 of the Vehicle Code; and

-Pursuant to the authority vested in the undersigned by Section {3902} of
 the Health and Safety Code;

 IT IS ORDERED AND RESOLVED:   That the installation of the IHC "Fleetrite"
 breakerless inductive ignition system manufactured by the Prestolite Electrical
 Diviston, 511 Hamilton Strset, Toledo, Ohio 43694, has been found not to
 reduce the effectiveness of required motor vehicles pollution control devices
 and, therefore, is exempt from the prohibitions of Section 27156 of the
 Yehicle Code for 1975 and older model year vehicles except as follows:

      1)   Those vehicles originally equipped with breakerless ignition
           systems or dual point ignition systems where one of the points
           is used to retard timing for emission control.

      2)   Those 1966 through 1970 vehicies equipped with "NOx retrofit
           devices" with a 4° ratard in basic ignition timing (f.e.,
           Carter, Echlin, 3TP Air Computer, Pure Power — Electro—~NOx).

 IHC "Fleetrite" consists of an electronic pack, trigger wheel and pick up
 assembly, and wiring harness. This device is marketed for the following
 applications:                 .              '

           Engine                     Model

           AMC and GMC 8 cylinder     549621—C19
           AMC and GMC 6 cylinder     549622—C19
             {except Y—6)
            Ford 6 cylinder {extept   549623—C19
             V—6)
            Ford 8 cylinder           549624—C19
            Chrysler 6 cylinder       549625—£19
            Chrysler 8 cylinder       5496526—C19
             (361,; 383, 400, 413,
              426, 400 CID)            ,      '
            Chrysler 8 cylinder       549627—C19
           ~ (273, 318, 340, 360
              CID)


  This Executive Order is valid provided that installation instructions for
\— this device will not recommend tuning the vehicle to specifications
  different than those listed by the vehicle manufacturer.

  Changes made to the design or operating conditions of the device, as
  exempted by the Air Resources Board, that adversely affect the per—
  formance of. the vehicle‘s pol]ut1on control system shall invalidate
  this Executive Order

  Marketing of this device using an identification other than that shown
  in this Executive Order or marketing of this device for an application
  other than those listed in this Executive Order shall be prohibited unless
  prior approval is obtained from the Air Resources Board.

  This Executive Order does not constitute any opinion as to the effect that
  the use of this device may have on any warranty either expressed or implied
  by the vehicle manufacturer.

  THIS EXECUTIVE ORDER DOES NOT CONSTITUTE A CERTIFICATION, ACCREDITATION,
  APPROVAL, OR ANY OTHER TYPE OF ENDORSEMENT BY THE AIR RESOURCES BOARD BY
  ANY CLAIMS OF THE APPLICANT CONCERNING ANTI—POLLUTION BENEFITS OR ANY       j
  ALLEGED BENErIFS OF THE IHC FLEETRITE BREAKERLESS INDUCTIVE IGNITION SYSTEM
  DEVICE.

  No claim of any kind, such as "Approved by Air Resources Board" may be made
  with respect to the action taken herein in any advertising or other oral
  or written communication.

  Section 17500 of the Business and Professions Code makes unlawful,, untrue
  or misleadfing advertising, and Section 17534 makes violation punishable as
  a misdémeanor.

  Section 43644 of the Health and Safety Code provide as follows:

        43644. {a) No person shall install, sell, offer for sale, or
        advertise, or éxcept in an application to the state board for
        certification of a device, represént, any device as a motor    .
        vehicle pollution control device for use on any used motor vehicle
        unless that device has been certified by the state board. No
        person shall sell, offer for sale, advertise, or represent any
        motor vehicle pollution control device as a certified device
       which in fact is not a certified device. Any violation of this
        subdivision is a misdemeanor.                   —

  Any ‘apparent violation of the conditions of this Executive Order will be
  submitted to the Attorney General of California for such action as he deems
 advisable.             —

  Executive Order D—54—3, dated November 26, 1975 is still valid.

        tC                                                    M curch
  Executed at Sacramento, California, this     ] l    day of February, 19761

                                              omz(mi      c.\‘b“ul

                                             WILLIAM H. QEWIS, JR.
                                             Executive Officer


                              _ State of California
                                AIR RESOURéES BOARD

                                   March 6, 1975

                          ‘        Staff Report

     Evaluation of Prestolite Electrical Division "BID" Breakerless
        Inductive Ignition System for Exemption from the Provisions
                   of Section 27156 of the Vehicle gode


      1gggpductifin                                      .

      Prestolite Eiéctrica] Division, 511 Hamilton Streét, Toledo,
      Ohio 43694, has applied for an exemption for its "BID" break—

      erless inductive ighition system.       Prestb]ite Electrical Diviston

      intends to market this device for 1974 (1972 for Chrysler prcductg)

      and’o1aer modeT—year domestic vehfc?es equipped with a standard

      Kettéring ignition system.       Vehicles éfiuipped with dual point

      distributors, where one of the points are used t6 retard timing

      for emissions control, are specifically excepted.


o I1. > Device Description and Function

      The "BID" is a breakerless, retrofit ignition system utilizing a

      resonant, magnetic pick—up cqil'aqd a metallic "toothed" trigger

      whee! that Towers the magnetic field strength in,the pick—up cofl.

      This'valtage réductjqn triggers a_chanée in a unistab]e.switch which

      controls a power sQitching irgnsistpr.— This power transistor controls

      current flow to the‘primary of the OEM ignition.coii and the remainder

      of the standa}d Kettering ignition system.      The systém is pictured in

      Exhibit I.     This type of system is described in the February 14, 1973


     staff r&pcft entii]ed'“Evaiuation of Capacitive Discharge
     andrTransistorizedbIgnition Systems for Compliance with the Requfre-

     ments of Section 27156 of thé‘Vehicle Code".          The major effect of

     the instaliation of this device is the replacement of the OEM point

     system with a metal detecting switching system similar to Chrysler‘s

     CEM breakerless ignition system.


UII. Device Evaluation

    ~ The app?icafit submitted electrical characteristics data and emission

     data on a T972 International Harvester, Model 1010, with a 392—4V

    ¥—8 engine.     Tests were run according to the CVS—2 procédure

     uith.the vehicle in three conditions:
     i)   As received.                         -

     2)    Tuned to vehicle manufacturers specifications and

     3}   As in 2) but with Prestolite "BID" system installed.
     Yhe\fasults in Table ; are the averages of two tests for each condition.
