Approval Details

Valid E.O.

Validity

This Executive Order approved the specified parts on on October 29, 1975.
As of Monday, October 21st, 2024 this Executive Order has not been overturned or superceeded.

Approved Parts

Part NumberModels
626-006The following 1974 and older vehicles with concentric distributor breaker plates: GM & AM 8 cylinder engines with Bosch distributors

This Executive Order may be listed as:
  • C.A.R.B.E.O. D-62
  • Executive Order 62 / D62
  • ARB # D-62
  • Executive Order No: D-62
  • C.A.R.B. No. D-62
  • Resolution D-62
For Free CARB Executive Order Status verification, email an image of the device Executive Order label as well as the Year/Make/Model and Test Group # of the vehicle to [email protected]

Download: Executive Order D-62 PDF

D-62 Document:

CARB_D-62

State of California /?/ AIR RESQURCES BOARD L. EXECUTIVE ORDER D—62 . — Relating to Exemptions under Sction 27156 of the Vehicle Code TRW AUTOMOTIVE ELECTRONICS "LUMENITION BREAKERLESS IGNITION SYSTEM" Pursuant to the authority vested in the Air Resources Boérd by Section 27156 of the Vehiclie Code; and Pursuant to the authority vested in the undersigned by Section 39023 of the Health and Safety Code; IT IS ORDERED AND RESOLVED: That the installation of "Lumenition Breakerless Ignition System" manufactured and marketed by TRW Automotive Electronics, Davis and Capewood Streets, Camden, New Jersey 08103 has been found to not reduce the effectiveness of required motor vehicle pollution control devices, and therefore, issexempt from the prohibitions of Section 27156 of the ‘ \ Vehicle Code for the following 1974 and older model—year vehicles with concentric distributor breaker plates? . 1....> Mode? ©626—02¢:(4—cylindersengines with=Bosch: ditstributors) sio:=cos Voikswagen, Audi, BMW, Opel, Porsche, Ford Capriz Mercedes Benz 4 2. Model 626—023 (6 cylinder engines with Bosch distributors) ‘ BMW, Opel, Porsche, Ford Capri, Mercedes Benz 3. Model 626—028 (8 cylinder engines with Bosch distributors) Mercedes Benz n~ o o ~du——Modet=—626=—006—(8— cylinder—engines with Delco=d{striBU@tOrs ) o —= n cs—mmms ns General Motors and American Motors This system may not be used on vehicles with C—D ignition systems or . . dual point distributors.where ‘one—.of the points is .used—for— emission controls = . This breakerless ignition system consists of a control rotor (chopper), position sensor (light emitting diode), infrared detector and a transistor switching unit. This Executive Order is valid provided that installation instructions for this device will not recommend tuning the vehicle to specifications different than those listed by the vehicle manufacturer. . Changes made to the design—or operating conditions of the device, as exempted by the Air Resources Board, that adversely affect the per— formance of the vehicle‘s pollution control system shall invalidate this Executive Order. ‘,.

"LUMENITION BREAKERLESS IGNITION SYSTEM" — EXECUTIVE ORDER D—62 Marketing of this device using an identification other than that shown 2— in this Executive Order or marketing of this device for an application other than those listed in this Executive Order shall be prohibited unless prior approval is obtained from the Air Resources Board. ~This Executive Order ‘does not constitute any’op%nion'as~to*the~effeét ' that the use of this device may have on any warranty either expressed or implied by the vehicle manufacturer. THIS EXECUTIVE ORDER DOES NOT CONSTITUTE A CERTIFICATION, ACCREDITATION, APPROVAL, OR ANY OTHER TYPE OF ENDORSEMENT BY THE AIR RESOURCES BOARD OF — ANY CLAIMS OF THE APPLICANT CONCERNING ANTI—POLLUTION BENEFITS OR ANY ALLEGED BENEFITS OF THE"TRW LUMENITION ELECTRONIC IGNITION SYSTEM:! No ctaim of anykind ; such as ~"Approved—by Air—Resources: Board" may be made with respect to the action taken herein in any advertising or other oral or written communication. — Section 17500 —ofthe ‘Business— andProfess fons »Code>makes—unlawfuT;~untrue.. ‘or misleading advertising, and Section 17534 makes—violation punishable as a misdemeanor. :Sectionsw39130'and-39184uof—thewHea1th~andHSafety:Code-provide as—follows: "39130. ~No person shall install, sell, ‘offé@r for sale, oradvertise; — or, except in an—application to the board for certification of. a— m es ns device, represent, any device as a motor vehicle pollution control device unless that device has been certified by the board. No person shalllsell, offer for sale, advertise, or represent any motor vehicle po]lut1on control device as a— certified device which, in fact; is not a cert1f1ed devrce""‘Any"VToTatlon‘ofthis—section~ts~ a misdemeanor.‘ "39184. (a) No person shall install, sell, offer for sale, or adver— ‘ttise, or, except in~an application—to the board—for—accreditatton of —a device, represent, any device as a motor vehicle pollution control device for use on any used motor vehicle unless that device has been accredited —by. the. board. :No person shall selt,. offer. for—sale, adver=> tise, or represent any motor vehicle poliution control device as an ‘accredited device which, in fact, is not an accredited device. Any violation of this subdivision is a misdemeanor." ° — Any apbareflt violatiom of the—condittons of this Executive—Order will be submitted to the Attorney General of California for such action as he deems advisable. Executed at Sacramento, California, this— 5252726day of October, 1975. WILLIAM H. LEWIS, JR. Executive Officer

State of California AIR RESOURCES BOARD October— 8, 1975— Staff Report ‘ Evaluation of TRW Automotive EVTecetronmics‘! °~ "*3 se esc ce iak ces "TRW Lumenition Electronic Ignition System Conversion Kit" for Compliance with the Requirements of Sect1on 27156 of the California Motor Vehicle Code. Introductfon TRW Automotive Electronics, Davis and Copewood Streets, Camden, New Jersey-08103 has submitted a revised app]fication requefifing an _ exemption. from Section 27156 of the Ca]ifornia Motor Vehicle Code ~for the "TRW Lumenition Electronic Ignition System ConversionKih"L_lalllll c ~A previous application was denied {Staff report dated July 10, 1975) — . because of excessive retard on certain vehicle applications. _Vehicle Code Section 27156 prohibitsthe installation of any device or mechanisin which reduces the ‘effectiveness of~theemisston:control> syfitém.- ThevAfE ReéodrceéABaard has been gfénted_the,authpritx to,t exempt the devices or mechanisms from this prohibiffiqh.if~a'ffndiflg shows the device or mechanism will not adversely— affect the—per—.——. pile es formance of the emission control system. TRw'fs requesting an éxémbtiofi for 'ihSta11ation“of theldéviéé;on certain 1974 and older model year foreign and domestic make vehxc]es having four, six or e1ght cy11nJer engines with.conventional. breaker- point distributors and concentric breaker plates except those vehicies‘ equipped with dual point distributofs where one set 1s-used to retard timing for emission controls or those véfiib]es.equipped wi th eitfier 0Q.E.M. or aftermarket C—D ignition systems.

TRW Lumenition Electronic Ignition System Conversion Kit n October 8, 1975 II.. System Description The TRW/Lumenition Electronic Ignition System is a breakerless ignftton system kit intended to replace the breaker points within the distributor. It consists of a control rotor, a position sensor, and a transistor switchingunit;> This device utilizes the ignition coil supplied with the vehicle. The control rotor (chopper) isvplaced over the cam of the distributor and bas windows cut for four, six or eight cylinder engine — applications. The position sensor operates in conjunction with the control —rotor and consists of a light emitting diode and an'infrafed defiecfior; . The—signals derived—by the position sensor—are fed to a. power unit which > Camplifies the signal and accomplishes transistor switching ofthe primary voltage to the ignition coil.> {Reference Appendix A and B) . III. System Evaluation The applicant haé submitted data.compéring the_{gnition system characteristics with and withoutthe—device. >A brief'summary“u”»’ of their datav is shown below: Q1) Bosch Distributor — 4 cylinder 1965 and later models (Volkswagen, Audi, BMW, Mercedes Benz, Opel, Porsche,—Ford Capri) A. Centrifugal Spark Advance in Crankshaft Degrees — ‘Enging RPM C Baseline ' . Device ' 600 — — o h s 90 1400 . > ~ 10 ' 10 2000 > . 20 0_ 18 2600 20 0026 2s soul. . 26 3200 33 31

TRW Lumenition Electronic Ignition — System Conversion Kit . October 8, 1975 B. Vacuum Spark Advance in Crankshaft Degrees Vacuum in. Hg. _ _ Baseline _ _ Device 3 . . s O ul e s 0 60000 4000002 20 g _ 13 0 _ _ 13 15 - 13 ‘ 13 20 P 13 _ 2 13 C. Secondary Voltage Avaitlable KY {with load) Engine RPM Baseline . Device — 600 35 (17) . > .36 (15) 4000 0 > 27 (M)s 00— "37 (14) D. Secondary Voltage Rise Time in Microseconds Engine RPM L . _0 Baseline Device..; > 500 _ o 4000 25 >[ u> 26 E. ‘Spark Duration in Microseconds Engine_RPM — CCC Baseline ~ * Device * 600 1800 | 1700 4000 1600 1550 F. ‘Spark Energy in Millijoules Engine RPM Baseline — Device: 600 14.0 . 13.7. 4000 _ g.g 0— 10.6

TRW Lumenition Electronic Ignition . > System Conversion Kit . October 8, 1975 2) Bosch Distributor — 6 cylinder — 1968 and later models (Mercedes Benz, BMW, Opel, Porsche, Ford— Capri) A. Centrifugal Spark Advance in Crankshaft Degreés Engine RPM. . Baseline _ Device | 600 _ ‘o . 0 1400 4 . 2 2000 O 14 13.6 ~ 2600 > ce 16 3200 _ 2100 18 B._ Vacuum Spark Advance in Crankshaft Degrees Vacuum in. Hg. Baseline Device 3 ~ 0 0 6 10 8 9 10 0 _ _ 10 15 10 10 20 10 | 10 C. Secondary Voltage Available KV —(with load) Engine RPM Baseline Device 600 35 (17) — 36 0s) 3500 27 (13) — 31 {05) | D.. Secondary Voltage Risa Time in Microseconds Enging RPM Baseline Device 600 © 20 23 20 23 3500 26 25

~TRW Lumenition Electronic Ignition System Conversion Kit October 8, 1975 E. Spark Duration in Microseconds Engine RPM Baseline Device —" _ eoo . o 1800 _ 1600 3500 ' 1600 ~1400 . E. Spark Energy in Millijoules . . Engine RPM Baseline — Device 600 414.2 12.3 3500 9.8 ‘9.4 3) Mercedes Benz — 8 cylinder — 1975 model year A. Centrifugal Spark Advance in Crankshéft Degrees Engine RPM Baseline Device 600 > . . 0 . 0 1400 - 5 4 2000 . 12 — 10 2600 13 13 3200 13 13 B. Vacuum, Spark Advance in Crankshaft Degrees Vacuum in. Hg. O Baseline Device 6 0 _0 9 600. 4 15 15v 13 20. . 15 13

TRW Lumenition Electronic Ignition . System Conversion Kit . . October 8, 197. C. ‘Secondary Voltage Available KV (with load) Engine_RPM O Baseline Device _ 600 34 (20) — 36 (16) 3000 28— (14) 1 (13) D. Secondary Voltage Rise Time in Microseconds RPM . Baseline Device 600 35 25 3000 32 _ 8 27 E. Spark Duration in Microseconds Engine RPM Baseline _ Device —_ 600 1800 1650 3000 _ 1650 1500 | _F. Spark Energy in Millijoules Engine_ RPM Baseline > > Device 600 13.4 13.7 3000 9.0 — 9.9 4) Buick — 8 cylinder — 1967—1971 _ A. — Centrifugal Spark Advance in Crankshaft Degrees Engine RPM ; Baseline Device 600 ‘ 0 . 0 1400 5 ' 4 2000 14 14 2600 18 18 3200 20 20

TRW Lumenition Electronic Ignition «L. ‘ System Conversion Kit. . . . October 8, 1975 B. Vacuum Spark Advance in Crankshaft Degrees Vacuum in. Hg. Baseling Device. 6 . 0 0 9 | 3 2003 15¢ 15 {os 20 17 <o 1 C. Secondary Voltage Available KV {with load) Engine_RPM Baseling ' Device 600 20 32 (18) 32 (17 ) 3000 _ 28 (17) 30 (15 ) D. Secondary Voltage Rise Time in Microseconds RPM Baseline Device 600 ~— 30 — 26 3000 28 25 E. Spark Duration in Microseconds Engine RPM Baseline Device 600 © 1400 1400 3000 5 1100 1200 F. Spark Energy in Millijoules RPM > _ Baseline Device 600 ' 13.4 13.7 3000 9.0 9.9

TRW Lumenition Electronic Ignition System Conversion Kit oC October 8, 175 The following tests were conducted at the Air Resources Board Laboratory. 5) Bosch —Distributor — 4 cylinder — 1973 A. Centrifugal Spark Advance in Crankshaft Degrees Engine RPM © Baseline Device 600 0 0 1400 8 8 2000 130 _ 1 2600 . 18 16 3200 20.5 21 B. Vacuum Spark Advance in Crankshaft Degrees Vacuum in. Hg. Baseling Device 3 . 0 0 60000 1 1> 9 5 5 15 5 5 20 5 5 C. Secondary Voltage Available (with load) KV Engine RPM Baseline Device 200 _ 11 12° 800 16 14 4000 . 14 14

TRW Lumenition Electronic Ignfition System Conversion Kit October 8, 1975 -Secondary Voltage Rise Time in Microseconds Engine RPM ‘ BaseTine Device ~ 2oo _ 50 45 800 40 ‘ 40 4000 i 40 35 Spark Duration in Microseconds Engine RPM Baseline _ Device 200 700 ‘ 700 800 1000 . ' 850 4000 750 800 F. Spark Energy in Millijoules Engine RPM: Baseline Device 200 10.9 9.1 800 j 19.0 t 14.7 4000 12.0 _ ' 12.4 The data submitted by the manufacturer and tests made by the Air Resources Board Laboratory Showed that the device will not resuit in any modification of the spark ignition characteristics which . would tend to increase emissions in the above vehicles. IV. Pacommendation The staff recommends granting an exemption from the prohibitions of Section 27156 of the Vehicle Code for the following vehicles:

TRW Lumenition Electronic Ignition C System Conversion Kit October 8, 1975 1) Model 626—021 (4 cylinder engines with Bosch distributors) Volkswagen, Audi, BMW, Opel, Porsche, Ford Capri, Mercedes Benz 2*% 2) Mode?} 626—032(6 cylinder engines with Bosch distributors} BMW, Opel, Porsche, ford Capri, Mercedes Benz. 3) Model 626—028 (8 cylinder engines with Bosch distributors) . Mercedes Benz 4) Model 626—006 (8 cylinder engines with Delco distributors) General Motors and American Motors 10.

Exhibit A ‘ . — September 30, 1975 Mr. K.D. Drachand, Chief Vehicle Compliance Air Resources Board Laboratory 9528 Telstar Avenue Ei Monte, California 91713 RE: TRW/Lumenition Breakerless Ignition System Conversion Kit Dear Mr. Drachand: On September 26, 1975, Mr. R.J. Kenny pointed out to our Hr. Mc Cue that our kit no. 626—036 (Ford 6—cy1.) exceeded the ARB criteria for timing variation when centrifugal advance data is added to the vacuum advance data. We are presently analyzing this situation to determine the problem, if there is a problem. Meanwhile, in order not to hold up approval on the other models, we will temporarily withdraw our application for kit no. 626—036. We‘will resubmit 626—036 along with other kits at a later date. This leaves under application, per my—letter of August 15, 1975, and my letter of September 12, 1975, to Mr. Kenny with corrected data, the follow— . ing kits: 626—021 4—Cylinder Bosch 626—023 6—Cylinder Bosch 626—028 V8 Bosch 626—027 4—Cylinder VW (Bosch) Industrial 626—006 V8 Delco (GM and AMC) Can I assume that when our app11cat1on is approved, it will allow an 0.E {e.g. BMW) to sell vehicles in California equipped w1th the appropr1ate Lumenition installation? I look forward to hearing from you on our'app1ication. Very truly yours, TRW AUTOMOTIVE SUBSYSTEMS //fflm,’ /z%"'é\,_ Williamn P. Donohue Division Manager > . WPD/ rk co: Mr. W.C. Mc Cue $ COPECOD STRCETS + Cai PLANTY LOCATTONE: Canoan, wit s imowOun, Onvas10, Cayaba + FoReilPo, onradd, CaNa oA

Exhibit A July 3,. 1975 Mr . K.D. Drachand, Cfiief Vehicle Cempliance Air Resources Board Laboratory 9528 Telstar Avenue E1 Monte, California 91713 RE: yourLETTEROf J(1E 5, 1975———TRN LUMENITION BREAKERLESS IGNITION SY COHVERSIONKIT — Dear Hr. Drachand: The answers to your questions are as follows: (1)~ Test data requested is shown on the attached data sheefs 1 — 16. (2) Attached is revised Exhibft III, Part 1, showing part numbers as requested. — (3) The Lumenition system is not compatible with after—market or 0.E.M. C—D ignition systems, and we do not recommend interfacing the. two kinds of devices. The Lumention system is designed to replace the breaker points with a permanent, non—adjustable photo—optic trigger, which still uses the Kettering principle for energy storage. This means that the O.E.M. coil sees the same kind of signal it would receive if the points were still in place. If a vehicle has an existing C—D system, we reconmend replacing it with the Lumenition sys tem and a standard coil and standard spark plugs. The Lumenition system is not compat1b1e with dual point distributors where one set of points is used to retard timing for emission control. . As a result, we do not have kits for such vehicles. (5) To our knowledge, the only vehic]es we retrofit with unequal .cam angles are pre—1968 Type 1. 2 and 3Vu1k,wagcns Ac;ord1ng to Volkswagen of America, the number 3 spark plug firing was retarded 3° to overcome an overheating problem with that cylinder. VW of America recormends to its! dealers. to replace worn pre—1968 distributors with new dis— tributors. which have equal cam angles. To overcome the overheating problem, Lhey racominend retarding the spark 3° from original manu— facturer‘s specifications. TRW AUTOMOTIVE ELECTRONICS « DAVIS & COPEYOOGD STRFEYS + CAMUEN, uEW «ERSEY ogto® PHONE: (Go9) S6s usne + TWX: 710.891—7087 PLANT LACATIGNS: CnMtSt®, hewat hssy «) Arenerail ul Livos + COLLMGYOOD, CVTARIO, Cartana & Yolibnt©, cxtaRio, carane

Exhibit A i0 > | — 2 — C Mr. K.D. Drachand o July 3. 1975 Henceforth, our instruction sheets for Vo]ksvagen vehicles will carry the statemont: "On Type 1, 2 and 3 vehicles pr1or to 1968 Model Year, timing should be retarded 3° from manufacturer‘s specifications.". (6) The Lumenition systeim is fully compatible with electronic speed sensors . which are capable of utilizing a positive square wave signal as an input, such as the Dana, Carter and AQP—Electro—NOx speed sensors. (7)— The 8 cylinder Ford unit was delivered toryour office by Mr. W.C. McCue. We trust this information satisfies your requirements and paves the way to certification.— If you have any further questions, please call me at the number Tisted at the bottom of the f1rst page of thls letter. ‘ Very truly yours, TRW AUTOMOTIVEASUBSYSfEMS' lblfssPinsdb. r_,. _wP. Donohue Division Manager WPD/cnr Attachment ce: Mr. W.C. McCue

CGENERAL DESCRIPTION OF THE LUMENITION®SYSTEM Lumenition® is a breakerleés, optically triggered electronic _subsystem for controlling the ignition of a spark ignited internal combustion engine. As presently manufactured it is a retrofit package, making use of the OEM distributor by direct substitution for the breaker points, It is designed to use the OEM coil, but high performance requirements are met _ by the use of a special coil in conjunéfion with the electronic package. _ It operates as follows: Infrared radiation from a light emitting diode is focused on the junction of a phototransistor; a slotted sheet metal or plastic disc affixed to the distributor shaft interrupts the beam, producing \ an on—off signal for spark control. The opto—electronic trigger signal (basically a measure of crankshaft positién) is amplified and used to control a power semiconductor which < actualiy sfiit_ches the coil primary currefif and so controls the spark’ene_rgy. Since both the initi.ation z;nd interruption of the coil current are controlled ' 'By the optically generated sigfial, spairk tirn-ing is only a function of crankshaft position. The performance, then, is vei‘y much the same as a properiy . adjusted breaker point system, but the absence of any moving parts in rubbing contact makes the initial timing adjustments permanent.

Tr<&rR aze me uw cls ll 7777 gN D. To penme Figure : 2 — vC;)ZCc)jT' D/HG/'C/‘?'“? EXNIDIT A '7‘1./3 73 /‘),// 75

Exhibit A pmrt m o e e oR e & ~7 1 , Ccort ss ;1: _,{Posagrom Se»sor |___ n yAnpurier® } — 2no | . PLUC;_S | o | ; | Flguzkr 3 — Sysrem Bisex BDinesrorm

148 1 RLLALLUN 2 ING L NU SE 4 uiss 4 is oggare oo merrs a ues o FOR BOSCH 4 CYL1iMDER CLOCKWISE ROTATION (626—021) BOSCH 4 CVLAMETR COUTER CLOCKWISE ROTATION <626—022)— “Appe’nd‘ix B .nm AnD FAMILIARIZE YourseLP wiTé ThE InstfuctTons, placzans, Ab Parts. ergprariow ' 1. mits «it Is for use on veHictes with necarive snoumo. > 2. se sure your xir is snewririeo For The DistaiBuror im your VesicLE. 3. turms foutrion settce orf. u9n Foap orstetsuror (rerem to Fiouse 1) — ' L4 > fLENéED uyq 1. pissetauros rrsparation . . 1 a. orem bistaisuror, Leavine s>me pLuS wikes in CaP, m REOVE AND RetALn—Rotor, . sls . Lo. g.. Rekove ano Discaad Dust cover (IF so eaurrrep), Potits, anp conpenser, p. Renove ano piscaro Polir HWIRE an crowmet From Bistrimutam, Discont@crtnG * PotiT Wike Fack neoktive CoTL TerminaL. i g. on pisffTauroms wilch have a rvioy or ridem rost wite—srrmne, The Post must be SporremeD AS FoLLOWSt 1) remorg ano olScaRD RETAINING CaP AnD seains, C2) passs ruantshco tACE T can comt Over PosT HALE ha¥, (3) emase rost with ?lzl.. 3 A PULE wille Pus#inG. CA® bovn To. SaT, & FimmLy on ruATE, ano (4) cut ose Tor romtion or rost Aaprroxnwteny 1/4 aBove CAP for ormem sLADE ClemraNice, For pisTRIzuTORs WITH A METAL post, This ST€P Is Un¥ecessaay. ‘ > — 2. terseer insrariation 1 .. Fien telsser carce Thrcyon mstne, . THE pistiauTor roint Wine hole FroM The ' ; { CLOOCWSE Romou Snownt. ANNCLCCmEE FeraTieni Lews a.o INSTALL TRIGGER tIF on wountine Prae USING extstinc rolkt HounTne 1 omtar.Bin Weoye Comesl screws, > t WiL SE GocesTe,. C 1 wire rasng SLIDE shormer ovge Trigser LEADS AUD INSTALL tNTo DrstRtauror HULE'FRUH MB‘ cone The oursibe. cHeck ror FIT. 3. evosesk instauLation | > ' . ; 10 — \ . LocaTe Chopres over can, rRess pawn cENTLY o cHorper White ROTATING 1 WiirpL AlTonmenT rs Acktevep. > 3 } B. USING FAX BELT, MaWUALLY rorare ENGINE UNFtL chopPer suaves C);EAR 1 rricser. — . c. Press Chorre® FiRMLYDowMana unTIL TT Is Fucty Seaten on can. : D. (ifeck thar Tugee ts mo inTeafenancs setizen chorrer alades anb retcose .‘ n~ k 5 « mne > By NatuaLiy Roratic Enolne; sta0gS SHouD ROTATE APPROXIMRTELY HALF j VIEW LOOKING DowN INTO DisTRiBuTO® with atay seviaen optics. > caPr, pust CovEn,AND Rofor removep 7 routs Triccer LekDs thstbe pistriteuTo® To Ensure cleamance of The choreer. * *. FXGU;E ho hoi hoe rovor ano Distrisuror ca», cueck sPatk PLUG wiRes for Tisuthess. Lt c Nd 6. mnser® iess comecror riMs INTO conmecror HoustNG as shown orteNtine BLack wine Towano TameRED ebse Or conmecror. hake Suae TEAmINALS Lock Ino > comcros Motstne. 222 mes= s 1. Moabntin > U 1 2 PowER AMPLIE power roouue {nasen to rreure 2) Po— **to seus rappine =" 1. tocats surtasce hountine anea. sls Sorenom Scheves.rean. ' — swrce A. lat ArBA 6n x Uru, ®. hust Rave Free ATR hovanenT, * C. Away FRow Rabfant wEA sources such as Exiaust Mawteoun. 2. use The rovee Meouke as A TemPLATE ANO samk ore mountIns Hores on THs woustine sueace. Make sumg Yhexe IS Clexrance FoR casLe. ' <=. 3. «pamnt 5/32 tn praweten woues Ar market—ore mownting Locations. ishtion 4.5 articw rower mosuce wti #10 serr—raepine scrgus suppiten. | . ’ _ 5, securs cnouin Leap To A welt srounbeb suarace. scrare To Bare METAL To assure A co09 comecr tow. — EIRAL roog—up 1. prrss tys Thrsesins cesur rusoton ThE eNotis comrantmenT Fron Ths rower t td P.DD\;:‘FA.E To Im€ DISTRISUTOR RAKLNG surk 1y clears Roving rafTs AND Hor > c surfaces. <o> — 2. goin the Thrse—wIns comecton fRom THE Power hoouts yo Te rreviousiy InsfALED connecrar Faow Yee otstarsurca. # commecton is «even ao l WILL GaLY Jor\ Oe ay.) B2 sume RED is to Rep, sLue 18 To sLUR, mLack Conmector Is To stack. . FLGURE 2 3. croute e meo—wime casle Yo ThE con. afeA, HAK(NC sure TT ctears hovine . Parts AnD HEaT sumraces. * & comser Buug teanihac. To Necative Teantnat of EO!L‘ (sonerimes L‘ASELEQ DistaTsutor). ih18 (s The TemMlilaL Fron waicy the Point Wike was ReFoVp, «* 5.. comeer ns TermiNaL To Tee PostTive Eh0 o7 The S:oxL. (rosttive. TeRSHHAL HAS LEaD Miice Comisis To IGHITTON SWITCH) — 6. noime Timine To havugacturea‘s seec. Ters ts a RixED pweLL anels | : > ‘ — s¥siEw auD ShOULD Reovire No reRtoDIC TimiM6 Apuustments, — — piSTRIBY TOR 7. exotse ts now meant vo Rum. * ‘ ' >

TESTING INSTRUCTIONS FOR TRW/LUMENITION IGNITION SYSTEM (NEGATIVE GROUND ONLY) F the—system is operating we do not recommend routine tesfing. ectronics do not deteriorate and therefore only the spark plugs, rotor arm, distributor d spark plug leads require checking, service, or replacement. n the event that the system is not functioning first check all conmnections. In partifcular, erify that a good ground connectfon exists all the way to the battery. Iif in doubt, emporarily jumper battery negative terminal to ground terminal of power unit. he system comprises three main components: POWER AMPLIFIER ASSEMBLY — TRIGGER ASSEMBLY (LENSED UNIT} cHoprer ) TO TEST COMPLETE SYSTEM ‘T) Remove the spark coil High Tension (H.T.) lead from the distributor and hold it 1/4" from grounded frame. On cranking the engine sparking should occur between the lead and frame. 3 TO TEST THE POWER AMPLIFIER ASSEMBEY 1)° Unp]ug the dlstrlbutor at the 3—pin connector. 2) Remove the H,T Coil lead at the distributor and hold it 1/4" to 1/2" from a good ground. 3) .Turn on the ignition switch. ‘) Ey means of a small piece of wire shaped like a hair pin connect the b?u;e wire to the ‘"black wire on the heat sink side of the 3—pin connector. When breaking this connection sparks should occur between the H.T. lead and ground. 5) —If there is a very weak spark check the colil. If there is no sfiark suspect a power amplifier fault. 6) Before testing trigger, verify that correct voltages exist at power amplifier. terminals. _With connector disconnected, the following voltages should exist with ignition on: 3—pin connector between black (~) and red (+]) leads 7V + IJV . 3—pin connector between black (~) and blue (+) leads 0. EV + 0. 3V vehicle frame to battery ground: less than O.1V vehicle frame to blue ring terminal: 12 + 2V vehicle frame to red ring terminal: 12 +2V (battery voltage} vehicle frame to black ring terminal (ground)} less than O0.1V TESTING THE TRIGGER ASSEMBLY (LENSED UNIT) This test is only valid with a good Power Amplifier Assembly. With the TRW/Lumenition system completely wired up, including the 3—pin connector, and the ignition switch on, connect the positive lead of Voltmeter carefully to the blue lead at the back of the 3~ pin connector, and connect the negative lead of the Voltmeter to the black ring terminal. With an uninterrupted beam of light between lenses the meter should read 0.1 to 0.2 volts. With an interrupted beam of light the meter should read 0.6 to 0.9 volts (use finger to .’nterrupt light beam). Before suspecting Lensed Unit ensure good Voltmeter con»nections. NOTE: The light beam is invisible to the human eye? FORM 6315
